V Bank Compact Filter

  • Box efficient air filter
  • Box efficient air filter
  • Box efficient air filter
  • Box efficient air filter
  • Box efficient air filter
  • Box efficient air filter
Box efficient air filter Box efficient air filter Box efficient air filter Box efficient air filter Box efficient air filter Box efficient air filter

Box efficient air filter

  • Brand:GAOKE
  • Size:Customize
  • Efficiency:H13-H14(99.99%-99.999%)
  • Product description: Box efficient air filter
  • INQUIRY

HEPA filter box

Features
●Long service life
●Large volume, low resistance and large amount of dust
●For large volume air conditioning and ventilation system

Standard specification

※ Media:Wet-laid glass fiber

※ Frame:ABS plastic,aluminum sheet,galvanized steel sheet.
※ V-shaped filter design to maximize media and filter life for optimal performance
※ Pleat media is sealed in polyurethane around the perimente of filter ensuring a leak design eliminating particle by-pass
※ Leakage testing by unit before leaving factory and provide testing report
※ Different sizes and specifications are available.
※ Efficiency:H11(EN1822),≥95% @ MPPS  ≥99% @ 0.3um
H13(EN1822),≥99.95% @ MPPS  ≥99.99% @ 0.3um
H14(EN1822),≥99.995% @ MPPS  ≥99.999% @ 0.3um
※ Recommended final Pressure drop:600Pa

Standard specification

model

Outside dimensions
(mm)

Rated air flow
(m3/h)

Imitial resistance(Pa)

Efficiency
(%)

v slots

CJ--H4-H1

305×610×295

1600

≤250 or ≤150(HV)

≥99.99

4V

CJ--H4-H2

610×610×295

3200

≤250 or ≤150(HV)

≥99.99

4V

CJ--H4-H3

305×610×295

2000

≤250 or ≤150(HV)

≥99.99

5V

CJ--H4-H4

610×610×295

4000

≤250 or ≤150(HV)

≥99.99

5V

According to user requirements to customize different specifications and types of filters
